Available now

Water monitoring & control

Xhuma Water Sensor

Wireless tank level monitoring and pump control, supplied as a complete system with a BASE station and SENS sensor.

Wireless Sensor Link 4G Connectivity Wi-Fi Gateway 1-Year Sensor Battery Pump On/Off Control Level Display iOS & Android App

Technical information

Sensor

Maximum tank depth	3 metres
Sensor-to-base distance	50 metres maximum
Battery type	4 × AA
Battery life	1 year

Pump output & connectivity

Pump voltage	230Vac, 1-phase
Maximum current	10 A
Maximum pump rating	1.1 kW
Contactor voltage	230Vac, 1-phase
Network options	Wi-Fi, 4G
Gateway power plug	SA 1877

Standards compliance: EN 61131-2:2007, EN 61010-1:2010+A1:2019, EN IEC 61010-2-201:2018, EMC Directive 2014/30/EU.

Available now

Maxi

Ultra-low-power connected data logger for long-life field deployment.

Field data logger

Long-life connected monitoring

Enquire

Maxi provides cellular, LoRaWAN, and NB-IoT connectivity options for data collection where long service intervals and rugged field deployment matter.

IP67 Enclosure 5+ Year Battery 2G / Cat-M / NB-IoT LoRaWAN Option Dual 4–20 mA Inputs microSD Storage 12V Sensor Excitation Cloud / IoT Ready Programmable

Technical information

Processing & connectivity

MCU	STM32L072 ultra-low-power MCU
Clock	Inbuilt precision RTC
Storage	microSD card up to 256 GB
Field programming	Supported
Cellular modem	SIM7070
Network options	2G / Cat-M1 / NB-IoT / optional LoRaWAN

Inputs & power

Inputs	Dual 4–20 mA
Sensor excitation	12V
Battery	2 × ER34615H
Capacity	38,000 mAh
Typical service life	5+ years
Enclosure	IP67

Applications: Water Level, Agriculture, Pressure Data, Environmental, Asset Tracking, Game Farms, and Site Security.
Standards compliance: EN 61131-2:2007, EN 61010-1:2010+A1:2019, EN IEC 61010-2-201:2018, EMC Directive 2014/30/EU.
